Avanti Plus® Series

Considered our platinum series, the Avanti PLUS® includes an award winning design and industry leading energy ratings. It’s also one of the quietest split systems on the market and incorporates an energy saving motion sensor, improved automatic mode for even more precise temperature control as well as ‘Clean Air Technology’ which captures and neutralises fine smoke particles, allergens, odours bacteria and viruses.


POWER: Single Phase  | AVAILABLE IN: Reverse Cycle

CAPACITIES: 2.0kW | 2.5kW | 3.5kW | 5.0kW | 6.0kW

Key features

  • Industry leading energy efficiency
  • Whisper quiet operation
  • Energy saving motion sensor and eco operation
  • Clean Air Technology to capture and neutralise allergens, odours, bacteria & viruses
  • Improved auto mode for precise temperature control


SELECT A CAPACITY TO VIEW SPECIFICATIONS

Single Phase
Specifications
SELECTED MODEL: SRK20ZSA-W / DXK06ZSA-W
Capacity
COOLING:
HEATING:
Energy Labels
Hot
COOLING:
HEATING:
Average
COOLING:
HEATING:
Cold
COOLING:
HEATING:
Dimensions (HxWxD)
INDOOR:
OUTDOOR:
Australia’s Best
Air-Conditioner Brand
We’re proud to be recognised by Finder as Australia's best brand of air-conditioners 3 years in a row.
Energy Saving
Fuzzy Auto Mode

Using fuzzy logic algorithms, the unit determines the operating mode and temperature settings automatically and adjusts the inverter frequency.

Motion Sensor

Infrared motion detector that monitors activity within the room and saves energy by adjusting temperature accordingly.

Eco Operation

Automatically adjusts the set temperature based on activity detected by the motion sensor and switches the unit off when no activity is detected.

Comfort & Convenience
Automatic Operation

Automatically selects the required heating or cooling function based on the current room conditions and set temperature.

Dry Operation

Reduces humidity by removing moisture from the air without affecting indoor temperature.

Hi Power Operation

Provides 15mins of boosted power to quickly heat or cool your home before returning to normal operation. Perfect for when you first turn on it the unit.

Silent Operation

Set periods of time where the unit will operate with reduced noise levels, perfect for night time and an uninterrupted sleep.

Night Setback

Designed for the colder seasons, this function ensures the room temperature is kept at around 10˚C, even while unoccupied.

Weekly Timer

Set your unit to turn on and off at specific times for each day of the week to suit your needs.

Sleep Timer

Set a pre-determined amount of time between 30 and 240 mins that your unit will operate for before switching off.

On/Off Timer

Set your unit to turn on and off once, at specific times, within a 24 hour period.

Preset Operation

The desired preset operation mode can be enabled with a single touch of a button.

Child Lock

Lock the remote control to prevent little ones from changing functions and other settings. Useful for families with curious young children.

LED Brightness Adjustment

Adjust the brightness of the LED display on the indoor unit to minimise disturbance during evenings. Perfect for units installed in bedrooms.

Air Flow
Jet Air Technology

Advanced fan blade technology, used in the development of jet engines, efficiently delivers powerful yet quiet and evenly distributed airflow.

Vertical Auto Swing

Set the louvres to move up and down continuously or set the louvre positions to single position.

3D Auto Airflow

One touch program that operates three independent motors which effectively distributes an even airflow across the entire room.

Auto Louvre Mode

Depending on whether the unit is in heating or cooling mode this will automatically set the louvre at the optimum angle for even air distribution.

Memory Louvre

Set the louvre at the desired angle. Unit will automatically return the louvres to this position on every subsequent start up.

Up/Down Louvre Swing

The horizontal louvres will automatically swing up and down for even air distribution.

Right/Left Louvre Swing

The vertical louvres will automatically swing left and right for even air distribution.

Clean Air Technology
Allergen Clear Filter

Captures airborne allergens such as hair, pollen and dust particles before neutralising them and any bacteria using specially formulated enzymes.

Allergen Clear Operation

Multi-stage operation that activates enzymes in the specially designed filter, neutralising and suppressing airborne allergens such as pollen, dust and hair.

Self-Clean Operation

Dries the indoor unit's filter and other internal components, preventing the growth of mould.

Photocatalytic Deodorizing Filter

Easy to clean filter that catches airborne allergens and particles before neutralising odour causing bacteria within them.

Maintenance
Back Up Switch

If the remote control fails, the unit can be operated via an on/off switch on the indoor unit.

Microcomputer-Operated Defrosting

Automatically activated during low ambient temperatures to prevent the frosting of the outdoor heat exchanger.

Self-Diagnostics

In the unlikely event of a fault the internal microcomputer automatically runs a diagnostic of the system. This enables a service agent to quickly isolate and repair any issues.

Auto Restart Function

If there is a temporary loss of power, when power is restored, the unit will automatically restart in the same operating mode it was in.

SELECT CONTROLLER TYPE FOR DETAILS:
Wireless Remote
Wi-Fi
High Power Mode
Provides 15mins of boosted power allowing you to quickly heat or cool your home.
Eco Operation
Automatically adjusts the set temperature based on activity detected by the motion sensor, saving energy.
LED Brightness Adjustment
Adjust the brightness of the LED display on the indoor unit.
Weekly Timer
Set your unit to turn on and off up to 4 times each day of the week.
On/Off Timer
Set your unit to turn on and off once within a 24 hour period.
3D Auto Mode
Activates three independent motors which effectively distributes a more even airflow.
Self Clean Operation
Dries the indoor units internal components, preventing mould and odours.
Dry Operation
Reduces humidity by removing moisture from the air without affecting indoor temperature.

For more information on the functions available and how to access them on your remote control, please refer to your unit’s user manual. For all features & functions, please view our split systems brochure here.

Download Manual

Control your system using your smart device (iPhone, iPad) or internet browser via to easy to use AC Cloud Control app*.

  • Control the set temperature, operation mode and fan speed.
  • Control your system via your Google or Amazon smart speaker device.
  • Control your system using Voice Command.
  • Set up ‘favourite’ scenes and activate them with a single tap.
  • Set your system to respond to the weather, you arriving home, calendar events + more**.
  • Receive instant notifications and email updates and create usage logs**.

*Wi-Fi control requires MH-AC-WIFI-1 Wi-Fi adaptor (sold separately)
**In conjunction with IFTTT and other apps (must be downloaded separately).
Note: Some functions for some air conditioners may not be available via AC Cloud Control app. On/Off timer, weekly timer and sleep timer are disabled if Wi-Fi accessory connected. Similar functions can be set via the AC Cloud application.

Download Manual
Avanti Plus® Series
Split Systems Brochure
Avanti Plus® Series
Split System Room Sizing Chart
Avanti Plus® Series
User Manual Avanti Plus (SRK20ZSXA-W, SRK25ZSXA-W, SRK35ZSXA-W, SRK50ZSXA-W, SRK60ZSXA-W)

What Makes Mitsubishi Heavy Industries The Experts in Air?

Ultimate Customer Satisfaction

Backed by award-winning technology, effortless performance, and unparalleled product reliability, we are dedicated to ensuring your complete satisfaction at every touchpoint.

Reliability

Designed to perform in the most demanding environments on earth, we engineer our products to endure its harshest conditions, from scorching summers, ice-cold winters and everything in-between.

Superior Technology

With world-class engineering and product innovation in our DNA, we push the boundaries to develop technology that delivers optimal experience. You can depend on us to deliver comfort in your home year after year.

Commitment to Our Customers

Standing behind the quality of our products is our commitment to our customers and after sales service guarantees with comprehensive warranties providing you peace of mind.
5 Years Parts and Labour Warranty
Standing behind our products and highlighting our commitment to our customers, all our air-conditioning systems are backed by a full 5 year parts and labour warranty.
TECHNICAL SPECIFICATIONS
ABCDEFGHIJ
1
IndoorSRK20ZSXA-WSRK25ZSXA-WSRK35ZSXA-WSRK50ZSXA-WSRK60ZSXA-W
2
OutdoorSRC20ZSXA-WSRC25ZSXA-WSRC35ZSXA-WSRC50ZSXA-WSRC60ZSXA-W
3
Power source (Outdoor Unit)1 Phase 240V 50Hz
4
*Operation
data
Nominal Capacity (Range)Cooling T1kW2.0 (0.9~3.4)2.5 (0.9~3.8)3.5 (0.9~4.5)5.0 (1.0~6.2)6.1 (1.0~6.9)
5
Heating H12.7 (0.8 ~5.5)3.2 (0.8~6.0)4.3 (0.8~6.8)6.0 (0.8~8.2)6.8 (0.8~8.8)
6
Heating H23.74.24.766.8
7
Power consumptionCooling T1kW0.31 (0.16~0.76)0.44 (0.16~0.91)0.74 (0.16~1.27)1.24 (0.19~1.90)1.71 (0.19~2.50)
8
Heating H10.47 (0.14~1.36)0.59 (0.14~1.54)0.90 (0.14~1.87)1.36 (0.20~2.46)1.65 (0.20~2.86)
9
Maximum power consumptionkW1.921.921.922.92.9
10
Running currentCooling T1A1.72.33.45.27.2
11
Heating H12.42.94.15.76.9
12
Inrush current, maximum currentA2.5, 9.03.0, 9.04.3, 9.05.0. 15.05.0, 15.0
13
EERCooling T16.455.684.734.033.57
14
COPHeating H15.745.424.784.414.12
15
Sound power level
(JIS C9612)
OutdoordB(A)5657616365
16
Sound pressure level
(JIS C9612)
IndoordB(A)38-31-24-1939-33-25-1943-35-26-1944-39-31-2248-41-33-22
17
Outdoor4344485152
18
Energy label (GEMS 2019)HOTCooling5.55543.5
19
Heating4.54.543.53.5
20
AVERAGECooling4.54.543.53
21
Heating443.533
22
COLDCooling4.54.54.53.53.5
23
Heating3.53.532.52.5
24
External dimensions (HxWxD)Indoormm305x920x220305x920x220305X920X220305X920X220305X920X220
25
Outdoor640x800(+71)x290640x800(+71)x290640X800(+71)X290640X800(+71)X290640X800(+71)X290
26
Net weightIndoorkg1313131313
27
Outdoor4343434545
28
AirflowIndoor (Cooling)l/s188-152-100-83203-167-112-83218-180-122-83238-207-130-90272-223-148-90
29
Indoor (Heating)203-172-120-90213-183-130-90232-197-143-90288-238-163-103297-228-182-103
30
Refrigerant (Type, amount, pre-charge length)Quantitykg(R32) 1.2(R32) 1.2(R32) 1.2(R32) 1.3(R32) 1.3
31
Pre charged to pipe lengthm1515151515
32
Installation dataRefrigerant pipingLiquid linemmØ6.35Ø6.35Ø6.35Ø6.35Ø6.35
33
Gas lineØ9.52Ø9.52Ø9.52Ø12.7Ø12.7
34
Connection methodFlare connection
35
Maximum pipe (one way) lengthm2530
36
Max vertical height diff. between O.U. and I.U.m15 ( O.U. above I.U. ) / 15 ( O.U. below I.U. )20 ( O.U. above I.U. ) /
20 ( O.U. below I.U. )
37
Standard accessoriesAllergen Clear & Photocatalytic Washable Deodorizing Filter
38
Optional partsInterface kit (SC-BIKN2-E) / Wi-Fi Kit
39
Demand response (AS4755)Yes
40
* Operation data has been gathered in accordance with AS/NZS 3823 standards.
